Water Level Indicator

Note: For more details send online enquiry

Product Name Download

Water Level Indicator

Download Brochure

Water Level Indicator

Model : KE-10

Used to detect leakage of water from the tubes of closed air circuit water cooled (CACW) cooler mounted on A.C. Motors.

Key features

  • Aluminum die cast enclosure.
  • Rugged design for long term use.
  • Accurate probe operation.
  • Straight & bend probe for different application.
  • IP-55 water ingress protection.

Specifications

1. Rated voltage :

110 / 120V AC or 200 / 240 V AC

2. Nominal frequency :

50 / 60 Hz

3. Temperature range :

0° to 55°C

4. Types of contacts :

Two changeover

5. Contact rating:

Contact rating Inductive Resistive
110 / 220 V DC 0.25A 0.5A
110 / 220 V AC 0.5A 5A
